PINE LIBRARY
Spectrum

Library "Spectrum"
This library includes spectrum analysis tools such as the Fast Fourier Transform (FFT).

method toComplex(data, polar)
Creates an array of complex type objects from a float type array.
Namespace types: array<float>
Parameters:
data (array<float>): The float type array of input data.
polar (bool): Initialization coordinates; the default is false (cartesian).
Returns: The complex type array of converted data.
method sAdd(data, value, end, start, step)
Performs scalar addition of a given float type array and a simple float value.
Namespace types: array<float>
Parameters:
data (array<float>): The float type array of input data.
value (float): The simple float type value to be added.
end (int): The last index of the input array (exclusive) on which the operation is performed.
start (int): The first index of the input array (inclusive) on which the operation is performed; the default value is 0.
step (int): The step by which the function iterates over the input data array between the specified boundaries; the default value is 1.
Returns: The modified input array.
method sMult(data, value, end, start, step)
Performs scalar multiplication of a given float type array and a simple float value.
Namespace types: array<float>
Parameters:
data (array<float>): The float type array of input data.
value (float): The simple float type value to be added.
end (int): The last index of the input array (exclusive) on which the operation is performed.
start (int): The first index of the input array (inclusive) on which the operation is performed; the default value is 0.
step (int): The step by which the function iterates over the input data array between the specified boundaries; the default value is 1.
Returns: The modified input array.
method eMult(data, data02, end, start, step)
Performs elementwise multiplication of two given complex type arrays.
Namespace types: array<cx.complex>
Parameters:
data (array<complex> type from RezzaHmt/Complex/1): the first complex type array of input data.
data02 (array<complex> type from RezzaHmt/Complex/1): The second complex type array of input data.
end (int): The last index of the input arrays (exclusive) on which the operation is performed.
start (int): The first index of the input arrays (inclusive) on which the operation is performed; the default value is 0.
step (int): The step by which the function iterates over the input data array between the specified boundaries; the default value is 1.
Returns: The modified first input array.
method eCon(data, end, start, step)
Performs elementwise conjugation on a given complex type array.
Namespace types: array<cx.complex>
Parameters:
data (array<complex> type from RezzaHmt/Complex/1): The complex type array of input data.
end (int): The last index of the input array (exclusive) on which the operation is performed.
start (int): The first index of the input array (inclusive) on which the operation is performed; the default value is 0.
step (int): The step by which the function iterates over the input data array between the specified boundaries; the default value is 1.
Returns: The modified input array.
method zeros(length)
Creates a complex type array of zeros.
Namespace types: series int, simple int, input int, const int
Parameters:
length (int): The size of array to be created.
method bitReverse(data)
Rearranges a complex type array based on the bit-reverse permutations of its size after zero-padding.
Namespace types: array<cx.complex>
Parameters:
data (array<complex> type from RezzaHmt/Complex/1): The complex type array of input data.
Returns: The modified input array.
method R2FFT(data, inverse)
Calculates Fourier Transform of a time series using Cooley-Tukey Radix-2 Decimation in Time FFT algorithm, wikipedia.org/wiki/Cooley–Tukey_FFT_algorithm.
Namespace types: array<cx.complex>
Parameters:
data (array<complex> type from RezzaHmt/Complex/1): The complex type array of input data.
inverse (int): Set to -1 for FFT and to 1 for iFFT.
Returns: The modified input array containing the FFT result.
method LBFFT(data, inverse)
Calculates Fourier Transform of a time series using Leo Bluestein's FFT algorithm, wikipedia.org/wiki/Chirp_Z-transform This function is nearly 4 times slower than the R2FFT function in practice.
Namespace types: array<cx.complex>
Parameters:
data (array<complex> type from RezzaHmt/Complex/1): The complex type array of input data.
inverse (int): Set to -1 for FFT and to 1 for iFFT.
Returns: The modified input array containing the FFT result.
method DFT(data, inverse)
This is the original DFT algorithm. It is not suggested to be used regularly.
Namespace types: array<cx.complex>
Parameters:
data (array<complex> type from RezzaHmt/Complex/1): The complex type array of input data.
inverse (int): Set to -1 for DFT and to 1 for iDFT.
Returns: The complex type array of DFT result.
