PINE LIBRARY

ToS

202
OVERVIEW

Contains methods for conversion to string of simple types int/float/bool/string/line/label/box.

- toS() - For bool/int/float works much the same as str.tostring() with some shorthand formatting options for int/float. For line/label/box displays their text and coordinates automatically formatting x coordinate as time or bar index.

- toShortString() - Converts a number to a short form using "k", "m", "bn" and "T" nominators. (e.g. `12,350` --> `12.4k`).
Supports some shorthand formatting options for int/float and time.

HOW TO USE

All toS() methods have the same parameters:
  Parameters:
    val (int): A float to be converted to string
    format (string): Format string, which depends on the value type
    nz (string): (string) A string used to represent na (na values are substituted with this string).

For toS(bool/int/float) format parameter works in the same way as `str.format()` (i.e. you can use same format strings as with `str.format()` with `{0}` as a placeholder for the value)

Some shorthand "format" options available:

--- number ---
- "" => "{0}"
- "number" => "{0}"
- "0" => "{0, number, 0 }"
- "0.0" => "{0, number, 0.0 }"
- "0.00" => "{0, number, 0.00 }"
- "0.000" => "{0, number, 0.000 }"
- "0.0000" => "{0, number, 0.0000 }"
- "0.00000" => "{0, number, 0.00000 }"
- "0.000000" => "{0, number, 0.000000 }"
- "0.0000000" => "{0, number, 0.0000000}"
--- date ---
- "... <date> ... " in any place is substituted with "{0, date, dd.MM.YY}"
- "date" => "{0, date, dd.MM.YY}"
- "date : time" => "{0, date, dd.MM.YY} : {0, time, HH.mm.ss}"
- "dd.MM" => "{0, date, dd:MM}"
- "dd" => "{0, date, dd}"
--- time ---
- "... <time> ... " in any place is substituted with "{0, time, HH.mm.ss}"
- "time" => "{0, time, HH:mm:ss}"
- "HH:mm" => "{0, time, HH:mm}"
- "mm:ss" => "{0, time, mm:ss}"
- "date time" => "{0, date, dd.MM.YY\} {0, time, HH.mm.ss}"
- "date, time" => "{0, date, dd.MM.YY\}, {0, time, HH.mm.ss}"
- "date,time" => "{0, date, dd.MM.YY\},{0, time, HH.mm.ss}"
- "date\ntime" => "{0, date, dd.MM.YY\}\n{0, time, HH.mm.ss}"


For toS(line):
    format (string): (string) (Optional) Use `x1` as placeholder for `x1` and so on. E.g. default format is `"(x1, y1) - (x2, y2)"`.

For toS(label):
    format (string): (string) (Optional) Use `x1` as placeholder for `x`, `y1 - for `y` and `txt` for label's text. E.g. default format is `(x1, y1): "txt"` if ptint_text is true and `(x1, y1)` if false.

For toS(box):
    format (string): (string) (Optional) Use `x1` as placeholder for `x`, `y1 - for `y` etc. E.g. default format is "(x1, y1) - (x2, y2)".

For toS(color):
    format (string): (string) (Optional) Options are "HEX" (e.g. "#FFFFFF33") or "RGB" (e.g. "rgb(122,122,122,23)"). Default is "HEX".


LIST OF FUNCTIONS AND PARAMETERS

method toS(val, format, nz)
  Formats the `int/float` in the same way as `str.format()` (i.e. you can use same format strings as with
`str.format()` with `{0}` arg) with some shorthand "format" options:
```
--- number ---
- "" => "{0}"
- "number" => "{0}"
- "0" => "{0, number, 0 }"
- "0.0" => "{0, number, 0.0 }"
- "0.00" => "{0, number, 0.00 }"
- "0.000" => "{0, number, 0.000 }"
- "0.0000" => "{0, number, 0.0000 }"
- "0.00000" => "{0, number, 0.00000 }"
- "0.000000" => "{0, number, 0.000000 }"
- "0.0000000" => "{0, number, 0.0000000}"
--- date ---
- "...<date>..." in angular brackets in any place is substituted with "{0, date, dd.MM.YY}"
- "date" => "{0, date, dd.MM.YY}"
- "date : time" => "{0, date, dd.MM.YY} : {0, time, HH.mm.ss}"
- "dd.MM" => "{0, date, dd:MM}"
- "dd" => "{0, date, dd}"
--- time ---
- "...<time>..." in angular brackets in any place is substituted with "{0, time, HH.mm.ss}"
- "time" => "{0, time, HH:mm:ss}"
- "HH:mm" => "{0, time, HH:mm}"
- "mm:ss" => "{0, time, mm:ss}"
- "date time" => "{0, date, dd.MM.YY\} {0, time, HH.mm.ss}"
- "date, time" => "{0, date, dd.MM.YY\}, {0, time, HH.mm.ss}"
- "date,time" => "{0, date, dd.MM.YY\},{0, time, HH.mm.ss}"
- "date\ntime" => "{0, date, dd.MM.YY\}\n{0, time, HH.mm.ss}"
```
  Namespace types: series int, simple int, input int, const int
  Parameters:
    val (int): A float to be converted to string
    format (string): Format string (e.g. "0.000" or "date : time" or "HH:mm")
    nz (string): (string) A string used to represent na (na values are substituted with this string).

method toS(val, format, nz)
  Formats the `int/float` in the same way as `str.format()` (i.e. you can use same format strings as with
`str.format()` with `{0}` arg) with some shorthand "format" options:
```
--- number ---
- "" => "{0}"
- "number" => "{0}"
- "0" => "{0, number, 0 }"
- "0.0" => "{0, number, 0.0 }"
- "0.00" => "{0, number, 0.00 }"
- "0.000" => "{0, number, 0.000 }"
- "0.0000" => "{0, number, 0.0000 }"
- "0.00000" => "{0, number, 0.00000 }"
- "0.000000" => "{0, number, 0.000000 }"
- "0.0000000" => "{0, number, 0.0000000}"
--- date ---
- "...<date>..." in angular brackets in any place is substituted with "{0, date, dd.MM.YY}"
- "date" => "{0, date, dd.MM.YY}"
- "date : time" => "{0, date, dd.MM.YY} : {0, time, HH.mm.ss}"
- "dd.MM" => "{0, date, dd:MM}"
- "dd" => "{0, date, dd}"
--- time ---
- "...<time>..." in angular brackets in any place is substituted with "{0, time, HH.mm.ss}"
- "time" => "{0, time, HH:mm:ss}"
- "HH:mm" => "{0, time, HH:mm}"
- "mm:ss" => "{0, time, mm:ss}"
- "date time" => "{0, date, dd.MM.YY\} {0, time, HH.mm.ss}"
- "date, time" => "{0, date, dd.MM.YY\}, {0, time, HH.mm.ss}"
- "date,time" => "{0, date, dd.MM.YY\},{0, time, HH.mm.ss}"
- "date\ntime" => "{0, date, dd.MM.YY\}\n{0, time, HH.mm.ss}"
```
  Namespace types: series float, simple float, input float, const float
  Parameters:
    val (float): A float to be converted to string
    format (string): Format string (e.g. "0.000" or "date : time" or "HH:mm")
    nz (string): (string) A string used to represent na (na values are substituted with this string).

method toS(val, format, nz)
  Formats `bool val` in the same way as `str.format()` (i.e. you can use same format strings as with
`str.format()` with `{0}` placeholder for the `val` argument).
  Namespace types: series bool, simple bool, input bool, const bool
  Parameters:
    val (bool): (bool) Value to be formatted
    format (string)
    nz (string): (string) A string used to represent na (na values are substituted with this string).

method toS(val, format, nz)
  Formats `string val` in the same way as `str.format()` (i.e. you can use same format strings as with
`str.format()` with `{0}` placeholder for the `val` argument).
  Namespace types: series color, simple color, input color, const color
  Parameters:
    val (color)
    format (string): (string) "HEX" or "RGB"
    nz (string): (string) A string used to represent na (na values are substituted with this string).

method toS(val, format, nz)
  Formats `string val` in the same way as `str.format()` (i.e. you can use same format strings as with
`str.format()` with `{0}` placeholder for the `val` argument).
  Namespace types: series string, simple string, input string, const string
  Parameters:
    val (string)
    format (string)
    nz (string): (string) A string used to represent na (na values are substituted with this string).

method toS(ln, format, nz)
  Returns line's coordinates as a string (by default in "(x1, y1) - (x2, y2)" format, use `x1`, `y1`, `x2`,`y2` as placeholders in `format` string)). Automatically detects
whether the coordinates are in `xloc.bar_index` or `xloc.bar_time` and displays
accordingly (in _dd.MM.yy HH:mm:ss_ format)
  Namespace types: series line
  Parameters:
    ln (line)
    format (string): (string) (Optional) Use `x1` as placeholder for `x1` and so on. E.g. default format is `"(x1, y1) - (x2, y2)"`.
    nz (string): (string) (Optional) If `val` is `na` and `nz` is not `na` the value of `nz` param is returned instead.

method toS(lbl, format, nz, print_text)
  Returns label's coordinates and text as a string (by default in "(x, y): text = ...)" format; use `x1`, `y1`, `txt` as placeholders in `format` string))).
Automatically detects whether the coordinates are in `xloc.bar_index` or `xloc.bar_time` and displays.
accordingly (in _dd.MM.yy HH:mm:ss_ format)
  Namespace types: series label
  Parameters:
    lbl (label)
    format (string): (string) (Optional) Use `x1` as placeholder for `x`, `y1 - for `y` and `txt` for label's text. E.g. default format is `(x1, y1): "txt"`.
    nz (string): (string) A string used to represent na (na values are substituted with this string).
    print_text (bool)

method toS(bx, format, nz)
  Returns box's coordinates as a string (by default in "(x1, y1) - (x2, y2)" format)
  Namespace types: series box
  Parameters:
    bx (box)
    format (string): (string) (Optional) Use `x1` as placeholder for `x`, `y1 - for `y` etc. E.g. default format is "(x1, y1) - (x2, y2)".
    nz (string): (string) A string used to represent na (na values are substituted with this string).

method toShortString(this, decimals)
  Converts number to a short form using "k", "m", "bn" and "T" nominators. (e.g. `12,350` --> `12.4k`).
this (series float) Number to be converted to short format.
@decimals (series int) Optional argument. Decimal places to which number will be rounded. When no argument
is supplied, rounding is to the nearest integer.
  Namespace types: series float, simple float, input float, const float
  Parameters:
    this (float)
    decimals (int)
